Reikia daugiau?
Kiekis | |
---|---|
1+ | 0,801 € |
10+ | 0,559 € |
25+ | 0,510 € |
50+ | 0,460 € |
100+ | 0,411 € |
500+ | 0,351 € |
Informacija apie produktą
Produktų apžvalga
The HLMP-EG3G-VX0DD is a high brightness red LED Lamp made of AlInGaP. It provides superior light output for excellent readability in sunlight and is extremely reliable. AlInGaP LED technology provides extremely stable light output over long periods of time. Precision optical performance lamp utilizes the aluminium indium gallium phosphide (AlInGaP) technology. This lamp is untinted, T-1-3/4 package incorporating second generation optics producing well defined spatial radiation patterns at specific viewing cone angles. It is made with an advanced optical grade epoxy, offering superior high temperature and high moisture resistance performance in outdoor signal and sign application. The maximum LED junction temperature limit of +130°C enables high temperature operation in bright sunlight conditions. The epoxy contains both UV-A and UV-B inhibitors to reduce the effects of long term exposure to direct sunlight.
- High brightness material
- -40 to 100°C Operating temperature range
- Superior resistance to moisture
- Superior performance for outdoor environments
- Suitable for auto-insertion onto PC board
- Well defined spatial radiation pattern
Pritaikymas
Signalling, Automotive, LED Lighting
Įspėjimai
Market demand for this product has caused an extension in leadtimes. Delivery dates may fluctuate. Product exempt from discounts.
Techniniai duomenys
Red
T-1 3/4 (5mm)
20mA
626nm
30°
-
MSL 1 - Unlimited
Through Hole
T-1 3/4 (5mm)
2.1V
9.3cd
Round
-
No SVHC (21-Jan-2025)
Techniniai duomenys (1)
Alternatyvos HLMP-EG3G-VX0DD
Rasta produktų: 1
Susiję produktai
Rasta produktų: 2
Teisinė ir aplinkosaugos informacija
Šalis, kurioje paskutinį kartą gamintojo atliktas stambus gamybos procesasKilmės šalis:China
Šalis, kurioje paskutinį kartą gamintojo atliktas stambus gamybos procesas
„RoHS“
„RoHS“
Gaminio atitikties sertifikatas
