SRP200F
Battery Strap PTC, PolySwitch SRP, 30 VDC, 2 A, 4.4 A, 4 s, 100 A
2 000 Galite rezervuoti pageidaujamą kiekį dabar
| Kiekis | |
|---|---|
| 1+ | 0,739 € |
| 50+ | 0,530 € |
| 100+ | 0,507 € |
| 250+ | 0,484 € |
| 500+ | 0,446 € |
| 1000+ | 0,413 € |
Informacija apie produktą
Produktų apžvalga
The SRP200F is a 2A PolySwitch Resettable Device with quarter-hard nickel leads and polyester tape. Raychem Circuit Protection, pioneer of polymeric PTC resettable device has developed several material platforms specifically tailored to help protect battery applications. Each of these material platforms offers different performance characteristics, allowing the engineer greater design flexibility. This SRP battery protector is compatible with high-volume electronics assembly and assists in meeting regulatory requirements. This resettable device increases battery operating time.
- Fast time-to-trip
- Low resistance devices increase battery operating time
Pritaikymas
Power Management, Portable Devices, Communications & Networking, Consumer Electronics
Įspėjimai
Intended for protection against occasional over-current or over-temperature fault conditions and should not be used when repeated fault conditions or prolonged trip events are anticipated.
Techniniai duomenys
PolySwitch SRP
30VDC
4.4A
100A
85°C
Strap
2A
4s
-40°C
-
Techniniai duomenys (2)
Alternatyvos SRP200F
Rasta produktų: 1
Susiję produktai
Rasta produktų: 1
Teisinė ir aplinkosaugos informacija
Šalis, kurioje paskutinį kartą gamintojo atliktas stambus gamybos procesasKilmės šalis:China
Šalis, kurioje paskutinį kartą gamintojo atliktas stambus gamybos procesas
„RoHS“
„RoHS“
Gaminio atitikties sertifikatas
