STTH1512PI
Fast / Ultrafast Diode, 1.2 kV, 15 A, Single, 1.2 V, 53 ns, 150 A
Reikia daugiau?
| Kiekis | |
|---|---|
| 1+ | 4,310 € |
| 10+ | 3,390 € |
| 100+ | 2,070 € |
| 500+ | 2,060 € |
| 1000+ | 2,050 € |
Informacija apie produktą
Produktų apžvalga
The STTH1512PI is a high-quality Ultra-fast Recovery Diode with low leakage current, regularly reproducible characteristics and intrinsic ruggedness. These characteristics makes it ideal for heavy duty applications that demand long term reliability. Such demanding applications include industrial power supplies and similar mission-critical systems that require rectification and free-wheeling. It also fits into auxiliary functions such as snubber, bootstrap and demagnetization applications. The improved performance in low leakage current and therefore thermal runaway guard band, is an immediate competitive advantage for this device.
- Soft recovery
- Very low conduction and switching losses
- High frequency and/or high pulsed current operation
- High reverse voltage capability
- High junction temperature
Pritaikymas
Power Management, Industrial
Techniniai duomenys
1.2kV
Single
53ns
175°C
2 Pin
-
15A
1.2V
150A
TO-220
STTH1
No SVHC (21-Jan-2025)
Techniniai duomenys (3)
Teisinė ir aplinkosaugos informacija
Šalis, kurioje paskutinį kartą gamintojo atliktas stambus gamybos procesasKilmės šalis:Philippines
Šalis, kurioje paskutinį kartą gamintojo atliktas stambus gamybos procesas
„RoHS“
„RoHS“
Gaminio atitikties sertifikatas
