DPO4102B

The DPO4102B Mixed Signal Oscilloscope delivers the performance you need to see fast-changing signal details. With automated serial and parallel bus analysis, innovative Wave Inspector® controls, and automated power measurements, this oscilloscope provides the feature-rich tools you need to simplify and speed debug of your complex design.

• 5 Megapoint Record Length (L version only and 20 Megapoint Record Length on all other models
• <gt/>50,000 wfm/s Maximum Waveform Capture Rate
• Passive Voltage Probes with Less than 4 pF Capacitive Loading and 500MHz or 1GHz analogue Bandwidth
• Suite of Advanced Triggers
• Wave Inspector® Controls provide Easy Navigation and Automated Search of Waveform Data
• 41 Automated Measurements, Waveform Histograms, and FFT Analysis for Simplified Waveform Analysis
• TekVPI® Interface supports Active, Differential, and Current Probes for Automatic Scaling and Units
• 10.4 in. (264 mm) Bright XGA colour Display
• Small Footprint and Lightweight – Only 5.8 in. (147 mm) deep and 11 lb. (5 kg)
• USB 2.0 Host Ports on Front and Rear Panel for Data Storage, Printing, and Connecting a USB Keyboard
• USB 2.0 Device Port on Rear for PC Connection or Direct Printing to a PictBridge®-compatible Printer
• 10/100/1000BASE-T Ethernet Port and Video Out Port to Export Oscilloscope Display
• Automated Serial Triggering, Decode, and Search Options
• Automated Triggering, Decode, and Search on Parallel Buses
• Per-channel Threshold Settings
• Multichannel Setup and Hold Triggering
• MagniVu™ High-speed Acquisition Provides 60.6 ps Fine Timing Resolution on Digital Channels

Pritaikymas

Power Management, System Monitoring, Imaging, Video & Vision

Pastabos

In addition, we have calibration services for this product (Europe Only). Visit our calibration service page to see details of what options are available.
