Fixed Network Resistors | Farnell Lietuva

Raskite platų Fixed Network Resistors asortimentą parduotuvėje Farnell Lietuva. Turime platų Fixed Network Resistors pasirinkimą, įskaitant naujus ir populiarius produktus iš geriausių pasaulio gamintojų, įskaitant: Panasonic, Bourns, Multicomp Pro, Yageo & Bourns / Partner Stock.

Gamintojo dalies nr.	Užsakymo kodas	Gamintojas / Aprašymas	Kaina už	Kaina (be PVM)	Resistance	Network Circuit Type	No. of Resistors	Resistor Case / Package	Resistor Terminals	Resistance Tolerance	Voltage Rating	Power Rating per Resistor	Temperature Coefficient	Resistor Type	Resistor Technology	Resistor Mounting	Terminal Pitch	Power Rating	Product Length	Product Width	Product Height	Product Range	Operating Temperature Min	Operating Temperature Max	Qualification

TC164-JR-0756RL	9234985 Data Sheet „RoHS“	YAGEO Fixed Network Resistor 56 ohm Isolated 4 Resistors 1206 [3216 Metric] Concave ± 5%	Each (Supplied on Cut Tape) Nupjauta juosta	10+0,047 € 100+0,031 € 500+0,0231 € 1000+0,0212 € 2500+0,0199 € Daugiau kainų variantų...	56ohm	Isolated	4Resistors	1206 [3216 Metric]	Concave	± 5%	50V	62.5mW	± 200ppm/°C	Array	Thick Film	Surface Mount Device	0.8mm	63mW	3.2mm	1.6mm	0.6mm	TC Series	-55°C	155°C	-
CAY16A-102J4LF	3769713 Data Sheet „RoHS“ Date/Lot Code	BOURNS Fixed Network Resistor 1 kohm Isolated 4 Resistors 1206 [3216 Metric] Convex ± 5%	Each (Supplied on Cut Tape) Nupjauta juosta	10+0,0628 € 100+0,0413 € 500+0,0323 € 1000+0,0271 € 2500+0,0261 € Daugiau kainų variantų...	1kohm	Isolated	4Resistors	1206 [3216 Metric]	Convex	± 5%	50V	63mW	200ppm/°C	Array	Thick Film	Surface Mount Device	0.8mm	-	3.2mm	1.6mm	0.5mm	CAY16A-LF Series	-55°C	125°C	AEC-Q200
CAT16-560J4LF	2908158 Data Sheet „RoHS“	BOURNS Fixed Network Resistor 56 ohm Isolated 4 Resistors 1206 [3216 Metric] Concave ± 5%	Each	10+0,029 €	56ohm	Isolated	4Resistors	1206 [3216 Metric]	Concave	± 5%	50V	63mW	± 200ppm/°C	Array	Thick Film	Surface Mount Device	0.8mm	250mW	3.2mm	1.6mm	0.5mm	CAT16 Series	-55°C	125°C	-
4116R-1-680LF	9355995 Data Sheet „RoHS“ Date/Lot Code	BOURNS Fixed Network Resistor 68 ohm Isolated 8 Resistors DIP PC Pin ± 2%	Each	1+2,590 € 3+1,960 € 5+1,780 € 10+1,600 € 20+1,550 € Daugiau kainų variantų...	68ohm	Isolated	8Resistors	DIP	PC Pin	± 2%	100V	250mW	± 100ppm/°C	Network	Thick Film	Through Hole	2.54mm	2.25W	21.97mm	6.71mm	4.57mm	4100R Series	-55°C	125°C	-
CAY16A-471J4LF	3769757 Data Sheet „RoHS“ Date/Lot Code	BOURNS Fixed Network Resistor 470 ohm Isolated 4 Resistors 1206 [3216 Metric] Convex ± 5%	Each (Supplied on Cut Tape) Nupjauta juosta	10+0,0534 € 100+0,0351 € 500+0,0277 € 1000+0,0253 € 2500+0,0241 € Daugiau kainų variantų...	470ohm	Isolated	4Resistors	1206 [3216 Metric]	Convex	± 5%	50V	63mW	200ppm/°C	Array	Thick Film	Surface Mount Device	0.8mm	-	3.2mm	1.6mm	0.5mm	CAY16A-LF Series	-55°C	125°C	AEC-Q200
CAY10-270J4LF	2787785 Data Sheet „RoHS“ Date/Lot Code	BOURNS Fixed Network Resistor 27 ohm Isolated 4 Resistors 1206 [3216 Metric] Convex ± 5%	Each (Supplied on Cut Tape) Nupjauta juosta	10+0,0836 € 100+0,0676 € 500+0,0558 €	27ohm	Isolated	4Resistors	1206 [3216 Metric]	Convex	± 5%	50V	62.5mW	± 200ppm/°C	Array	Thick Film	Surface Mount Device	0.5mm	250mW	3.2mm	1.6mm	0.35mm	CAY10 Series	-55°C	125°C	-
CAT16-224J4LF	2908150 Data Sheet „RoHS“ Date/Lot Code	BOURNS Fixed Network Resistor 220 kohm Isolated 4 Resistors 1206 [3216 Metric] Concave ± 5%	Each (Supplied on Cut Tape) Nupjauta juosta	10+0,0332 € 100+0,023 € 500+0,0211 € 1000+0,0176 €	220kohm	Isolated	4Resistors	1206 [3216 Metric]	Concave	± 5%	50V	63mW	± 200ppm/°C	Array	Thick Film	Surface Mount Device	0.8mm	250mW	3.2mm	1.6mm	0.5mm	CAT16 Series	-55°C	125°C	-
CAY16A-102J4AS	3769712 Data Sheet „RoHS“ Date/Lot Code	BOURNS Fixed Network Resistor 1 kohm Isolated 4 Resistors 1206 [3216 Metric] Convex ± 5%	Each (Supplied on Cut Tape) Nupjauta juosta	10+0,170 € 100+0,0534 € 500+0,0402 €	1kohm	Isolated	4Resistors	1206 [3216 Metric]	Convex	± 5%	50V	63mW	200ppm/°C	Array	Thick Film	Surface Mount Device	0.8mm	-	3.2mm	1.6mm	0.5mm	CAY16A-AS Series	-55°C	125°C	AEC-Q200
CAY16A-204J4LF	3769727 Data Sheet „RoHS“ Date/Lot Code	BOURNS Fixed Network Resistor 200 kohm Isolated 4 Resistors 1206 [3216 Metric] Convex ± 5%	Each (Supplied on Cut Tape) Nupjauta juosta	10+0,0448 € 100+0,0305 € 500+0,0275 € 1000+0,0252 € 2500+0,0235 €	200kohm	Isolated	4Resistors	1206 [3216 Metric]	Convex	± 5%	50V	63mW	200ppm/°C	Array	Thick Film	Surface Mount Device	0.8mm	-	3.2mm	1.6mm	0.5mm	CAY16A-LF Series	-55°C	125°C	AEC-Q200
CAY16-181J4LF	2008292 Data Sheet „RoHS“ Date/Lot Code	BOURNS Fixed Network Resistor 180 ohm Isolated 4 Resistors 1206 [3216 Metric] Convex ± 5%	Each (Supplied on Cut Tape) Nupjauta juosta	10+0,034 € 100+0,0235 € 500+0,0217 € 1000+0,0189 € 2500+0,0174 € Daugiau kainų variantų...	180ohm	Isolated	4Resistors	1206 [3216 Metric]	Convex	± 5%	50V	62mW	-	Array	-	Surface Mount Device	0.8mm	250mW	3.2mm	1.6mm	0.5mm	CAY16 Series	-55°C	125°C	-
MP000992	3228740 Data Sheet „RoHS“ Date/Lot Code	MULTICOMP PRO Fixed Network Resistor 560 ohm Isolated 4 Resistors 1206 [3216 Metric] Convex ± 5%	Each (Supplied on Cut Tape) Nupjauta juosta	10+0,0311 €	560ohm	Isolated	4Resistors	1206 [3216 Metric]	Convex	± 5%	50V	100mW	± 200ppm/°C	Array	Thick Film	Surface Mount Device	0.8mm	-	3.2mm	1.6mm	0.55mm	-	-55°C	155°C	-
4608X-102-102LF	9356517 Data Sheet „RoHS“ Date/Lot Code	BOURNS Fixed Network Resistor 1 kohm Isolated 4 Resistors SIP PC Pin ± 2%	Each	1+0,284 € 50+0,144 € 100+0,130 € 250+0,119 € 500+0,111 € Daugiau kainų variantų...	1kohm	Isolated	4Resistors	SIP	PC Pin	± 2%	100V	300mW	± 100ppm/°C	Network	Thick Film	Through Hole	2.54mm	1W	20.27mm	2.49mm	5.08mm	4600X Series	-55°C	125°C	-
4609X-101-103LF	9356819 Data Sheet „RoHS“	BOURNS Fixed Network Resistor 10 kohm Bussed 8 Resistors SIP PC Pin ± 2%	Each	1+0,318 € 50+0,151 € 100+0,135 € 250+0,123 € 500+0,115 € Daugiau kainų variantų...	10kohm	Bussed	8Resistors	SIP	PC Pin	± 2%	100V	200mW	± 100ppm/°C	Network	Thick Film	Through Hole	2.54mm	1.13W	22.81mm	2.49mm	5.08mm	4600X Series	-55°C	125°C	-
CAY16-1002F4LF	1770143 Data Sheet „RoHS“ Date/Lot Code	BOURNS Fixed Network Resistor 10 kohm Isolated 4 Resistors 1206 [3216 Metric] Convex ± 1%	Each (Supplied on Cut Tape) Nupjauta juosta	10+0,0411 € 100+0,0295 € 500+0,0266 € 1000+0,0243 € 2500+0,0227 €	10kohm	Isolated	4Resistors	1206 [3216 Metric]	Convex	± 1%	50V	62mW	-	Array	-	Surface Mount Device	0.8mm	62mW	3.2mm	1.6mm	0.5mm	CAY16 Series	-55°C	125°C	-
MCRNLA09G0103B0E	1973141 Data Sheet „RoHS“ Date/Lot Code	MULTICOMP PRO Fixed Network Resistor 10 kohm Bussed 8 Resistors SIP PC Pin ± 2%	Each	1+0,137 € 5+0,111 € 10+0,100 € 25+0,0929 € 50+0,0853 € Daugiau kainų variantų...	10kohm	Bussed	8Resistors	SIP	PC Pin	± 2%	100V	-	± 200ppm/°C	Network	Thick Film	Through Hole	2.54mm	200mW	22.9mm	2.5mm	5.08mm	MCRNLA Series	-55°C	125°C	-
TC164-FR-0710KL	9234853 Data Sheet „RoHS“ Date/Lot Code	YAGEO Fixed Network Resistor 10 kohm Isolated 4 Resistors 1206 [3216 Metric] Concave ± 1%	Each (Supplied on Cut Tape) Nupjauta juosta	10+0,0629 € 100+0,0417 € 500+0,0315 € 1000+0,0284 € 2500+0,0278 €	10kohm	Isolated	4Resistors	1206 [3216 Metric]	Concave	± 1%	50V	62.5mW	± 200ppm/°C	Array	Thick Film	Surface Mount Device	0.8mm	63mW	3.2mm	1.6mm	0.6mm	TC Series	-55°C	155°C	-
4116R-1-221LF	9355880 Data Sheet „RoHS“ Date/Lot Code	BOURNS Fixed Network Resistor 220 ohm Isolated 8 Resistors DIP PC Pin ± 2%	Each	1+2,820 € 3+2,480 € 5+2,140 € 10+1,800 € 20+1,660 € Daugiau kainų variantų...	220kohm	Isolated	8Resistors	DIP	PC Pin	± 2%	100V	250mW	± 100ppm/°C	Network	Thick Film	Through Hole	2.54mm	2.25W	21.97mm	6.71mm	4.57mm	4100R Series	-55°C	125°C	-
4609X-101-222LF	9356916 Data Sheet „RoHS“ Date/Lot Code	BOURNS Fixed Network Resistor 2.2 kohm Bussed 8 Resistors SIP PC Pin ± 2%	Each	1+0,301 € 50+0,151 € 100+0,135 € 250+0,123 € 500+0,115 € Daugiau kainų variantų...	2.2kohm	Bussed	8Resistors	SIP	PC Pin	± 2%	100V	200mW	± 100ppm/°C	Network	Thick Film	Through Hole	2.54mm	1.13W	22.81mm	2.49mm	5.08mm	4600X Series	-55°C	125°C	-
EXB28V220JX	2060031 Data Sheet „RoHS“ Date/Lot Code	PANASONIC Fixed Network Resistor 22 ohm Isolated 4 Resistors 0804 [2010 Metric] Convex ± 5%	Each (Supplied on Cut Tape) Nupjauta juosta	10+0,0462 € 100+0,0331 € 500+0,0299 € 2500+0,0255 € 5000+0,025 €	22ohm	Isolated	4Resistors	0804 [2010 Metric]	Convex	± 5%	50V	63mW	± 200ppm/°C	Array	Thick Film	Surface Mount Device	0.5mm	-	2mm	1mm	0.35mm	EXB-28V Series	-55°C	125°C	AEC-Q200
4609X-101-472LF	9357025 Data Sheet „RoHS“ Date/Lot Code	BOURNS Fixed Network Resistor 4.7 kohm Bussed 8 Resistors SIP PC Pin ± 2%	Each	1+0,318 € 50+0,151 € 100+0,135 € 250+0,123 € 500+0,115 € Daugiau kainų variantų...	4.7kohm	Bussed	8Resistors	SIP	PC Pin	± 2%	100V	200mW	± 100ppm/°C	Network	Thick Film	Through Hole	2.54mm	1.13W	22.81mm	2.49mm	5.08mm	4600X Series	-55°C	125°C	-
4605X-101-472LF	9356100 Data Sheet „RoHS“ Date/Lot Code	BOURNS Fixed Network Resistor 4.7 kohm Bussed 4 Resistors SIP PC Pin ± 2%	Each	1+0,241 € 50+0,114 € 100+0,0903 € 250+0,0826 € 500+0,080 € Daugiau kainų variantų...	4.7kohm	Bussed	4Resistors	SIP	PC Pin	± 2%	100V	200mW	± 100ppm/°C	Network	Thick Film	Through Hole	2.54mm	630mW	12.65mm	2.49mm	5.08mm	4600X Series	-55°C	125°C	-
YC124-JR-0733RL	9235272 Data Sheet „RoHS“ Date/Lot Code	YAGEO Fixed Network Resistor 33 ohm Isolated 4 Resistors 0804 [2010 Metric] Convex ± 5%	Each (Supplied on Cut Tape) Nupjauta juosta	10+0,0275 € 100+0,0181 € 500+0,0138 € 2500+0,012 € 5000+0,0118 €	33ohm	Isolated	4Resistors	0804 [2010 Metric]	Convex	± 5%	50V	62.5mW	± 300ppm/°C	Array	Thick Film	Surface Mount Device	0.5mm	62.5mW	2mm	1mm	0.45mm	YC Series	-55°C	125°C	-
4608X-102-103LF	9356525 Data Sheet „RoHS“ Date/Lot Code	BOURNS Fixed Network Resistor 10 kohm Isolated 4 Resistors SIP PC Pin ± 2%	Each	1+0,284 € 50+0,143 € 100+0,129 € 250+0,118 € 500+0,110 € Daugiau kainų variantų...	10kohm	Isolated	4Resistors	SIP	PC Pin	± 2%	100V	300mW	± 100ppm/°C	Network	Thick Film	Through Hole	2.54mm	1W	20.27mm	2.49mm	5.08mm	4600X Series	-55°C	125°C	-
4605X-101-103LF	9356061 Data Sheet „RoHS“ Date/Lot Code	BOURNS Fixed Network Resistor 10 kohm Bussed 4 Resistors SIP PC Pin ± 2%	Each	1+0,241 € 50+0,114 € 100+0,0903 € 250+0,0809 € 500+0,0766 € Daugiau kainų variantų...	10kohm	Bussed	4Resistors	SIP	PC Pin	± 2%	100V	200mW	± 100ppm/°C	Network	Thick Film	Through Hole	2.54mm	630mW	12.65mm	2.49mm	5.08mm	4600X Series	-55°C	125°C	-
YC164-JR-0710KL	9234560 Data Sheet „RoHS“ Date/Lot Code	YAGEO Fixed Network Resistor 10 kohm Isolated 4 Resistors 1206 [3216 Metric] Convex ± 5%	Each (Supplied on Cut Tape) Nupjauta juosta	10+0,0361 € 100+0,0232 € 500+0,0181 € 1000+0,0155 € 2500+0,0152 €	10kohm	Isolated	4Resistors	1206 [3216 Metric]	Convex	± 5%	50V	62.5mW	± 200ppm/°C	Array	Thick Film	Surface Mount Device	0.8mm	63mW	3.2mm	1.6mm	0.6mm	YC Series	-55°C	155°C	-
